Number of bus stations 64

Max. number of bytes fieldbus 512 byte input and 512 byte output

Digital peripheral signals 512 inputs/outputs

Analog peripheral signals 128 inputs/outputs

Configuration option via KS2000 or the controller

Data transfer rates 2.5 MBaud

Bus interface 2 x standard fiber optic connector Z1000 (synthetic fiber), Z1010 (HCS fiber)

Data transmission medium fiber optic conductor: APF (plastic) fiber (1,000 µm) or HCS fiber (200 µm)

Power supply 24 V DC (-15%/+20%)

Input current 70 mA + (total K bus current)/4,500 mA max.

Starting current approx. 2.5 x continuous current

Recommended fuse ≤ 10 A

Power supply K-bus 1750mA

Current contacts max. 24 V DC/max. 10 A

Electrical isolation 500 V (supply contact/supply voltage)

Distance between stations 45 m for APF fiber, 300 m HCS fiber

Data transfer time 0.26 ms at 10 modules for 32-bit inputs and outputs each (without K-bus runtime)

Weight approx. 150 g

Operating/storage temperature 0...+55°C/-25...+85°C

Relative humidity 95%, no condensation

Vibration/shock resistance complies with EN 60068-2-6/EN 60068-2-27

EMC immunity/emission complies with EN 61000-6-2/EN 61000-6-4

Protection class/installation pos. IP20/variable

Approvals/markings CE, UL, ATEX, IECEx

Ex marking ATEX: II 3G Ex ec IIC T4 Gc

IECEx: Ex ec IIC T4 Gc
